Inference for Influence Diagram

class pyagrum.ShaferShenoyLIMIDInference(infDiag)

This inference considers the provided model as a LIMID rather than an influence diagram. It is an optimized implementation of the LIMID resolution algorithm. However an inference on a classical influence diagram can be performed by adding a assumption of the existence of the sequence of decision nodes to be solved, which also implies that the decision choices can have an impact on the rest of the sequence (Non Forgetting Assumption, cf. pyagrum.ShaferShenoyLIMIDInference.addNoForgettingAssumption).

• Parameters: infDiag (InfluenceDiagram)

MEU(*args)

Returns maximum expected utility obtained from inference.

• Raises: pyagrum.OperationNotAllowed – If no inference have yet been made
• Return type: object

addEvidence(*args)

Adds a new evidence on a node (might be soft or hard).

• Parameters:
  • id (int) – a node Id
  • nodeName (int) – a node name
  • val – (int) a node value
  • val – (str) the label of the node value
  • vals (list) – a list of values
• Raises:
  • pyagrum.InvalidArgument – If the node already has an evidence
  • pyagrum.InvalidArgument – If val is not a value for the node
  • pyagrum.InvalidArgument – If the size of vals is different from the domain side of the node
  • pyagrum.FatalError – If vals is a vector of 0s
  • pyagrum.UndefinedElement – If the node does not belong to the Bayesian network
• Return type: None

addNoForgettingAssumption(*args)

• Return type: None

chgEvidence(*args)

Change the value of an already existing evidence on a node (might be soft or hard).

• Parameters:
  • id (int) – a node Id
  • nodeName (int) – a node name
  • val (intstr) – a node value or the label of the node value
  • vals (List [**float ]) – a list of values
• Raises:
  • pyagrum.InvalidArgument – If the node does not already have an evidence
  • pyagrum.InvalidArgument – If val is not a value for the node
  • pyagrum.InvalidArgument – If the size of vals is different from the domain side of the node
  • pyagrum.FatalError – If vals is a vector of 0s
  • pyagrum.UndefinedElement – If the node does not belong to the Bayesian network
• Return type: None

clear()

• Return type: None

eraseAllEvidence()

Remove all evidence.

• Return type: None

eraseEvidence(*args)

Remove the evidence, if any, corresponding to the node Id or name.

• Parameters:
  • id (int) – a node Id
  • nodeName (int) – a node name
• Raises: pyagrum.IndexError – If the node does not belong to the Bayesian network
• Return type: None

hardEvidenceNodes()

• Returns: the set of nodes with hard evidence
• Return type: set

hasEvidence(*args)

• Parameters:
  • id (int) – a node Id
  • nodeName (str) – a node name
• Returns: True if some node(s) (or the one in parameters) have received evidence
• Return type: bool
• Raises: pyagrum.IndexError – If the node does not belong to the Bayesian network

hasHardEvidence(nodeName)

• Parameters:
  • id (int) – a node Id
  • nodeName (str) – a node name
• Returns: True if node has received a hard evidence
• Return type: bool
• Raises: pyagrum.IndexError – If the node does not belong to the Bayesian network

hasNoForgettingAssumption()

• Return type: bool

hasSoftEvidence(*args)

• Parameters:
  • id (int) – a node Id
  • nodeName (str) – a node name
• Returns: True if node has received a soft evidence
• Return type: bool
• Raises: pyagrum.IndexError – If the node does not belong to the Bayesian network

influenceDiagram()

Returns a constant reference over the InfluenceDiagram on which this class work.

• Returns: the InfluenceDiagram on which this class work
• Return type: pyagrum.InfluenceDiagram

isSolvable()

check wether the influence diagram is solvable or not

• Returns: True if the influence diagram is solvable
• Return type: bool

junctionTree()

• Returns: the current junction tree
• Return type: pyagrum.CliqueGraph

makeInference()

Perform the heavy computations needed to compute the optimal decisions.

• Return type: None

meanVar(*args)

• Parameters:
  • id (int) – a node Id
  • nodeName (str) – a node name
• Returns: a dictionary with the mean and variance of the node (after the inference)
• Return type: dict[str, float]

nbrEvidence()

• Returns: the number of evidence entered into the Bayesian network
• Return type: int

nbrHardEvidence()

• Returns: the number of hard evidence entered into the Bayesian network
• Return type: int

nbrSoftEvidence()

• Returns: the number of soft evidence entered into the Bayesian network
• Return type: int

optimalDecision(*args)

Returns best choice for decision variable given in parameter ( based upon MEU criteria )

• Parameters: decisionId (int ,**str) – the id or name of the decision variable
• Raises: pyagrum.OperationNotAllowed – If no inference have yet been made
• Return type: Tensor

pyagrum.InvalidNode : If node given in parmaeter is not a decision node

posterior(*args)

Returns the posterior of a chance or a decision node (after optimisation).

• Parameters:
  • var (int) – the node Id of the node for which we need a posterior probability
  • nodeName (str) – the node name of the node for which we need a posterior probability
• Returns: a const ref to the posterior probability of the node
• Return type: pyagrum.Tensor

posteriorUtility(*args)

Returns the posterior utiliyt of a utility node (after optimisation) depending on decision nodes, if any.

• Parameters:
  • var (int) – the node Id of the node for which we need a posterior probability
  • nodeName (str) – the node name of the node for which we need a posterior probability
• Returns: a const ref to the posterior utility of the utility node
• Return type: pyagrum.Tensor

reducedGraph()

Returns the DAG build to solve the influence diagram.

• Returns: a copy of the reduced graph
• Return type: pyagrum.DAG

reducedLIMID()

Returns the (reduced) LIMID build to solve the influence diagram.

• Returns: a copy of the reduced influence Diagram (LIMID)
• Return type: pyagrum.InfluenceDiagram

reversePartialOrder()

setEvidence(evidces)

Erase all the evidences and apply addEvidence(key,value) for every pairs in evidces.

• Parameters: evidces (dict) – a dict of evidences
• Raises:
  • pyagrum.InvalidArgument – If one value is not a value for the node
  • pyagrum.InvalidArgument – If the size of a value is different from the domain side of the node
  • pyagrum.FatalError – If one value is a vector of 0s
  • pyagrum.UndefinedElement – If one node does not belong to the influence diagram

softEvidenceNodes()

• Return type: object

updateEvidence(evidces)

Apply chgEvidence(key,value) for every pairs in evidces (or addEvidence).

• Parameters: evidces (dict) – a dict of evidences
• Raises:
  • pyagrum.InvalidArgument – If one value is not a value for the node
  • pyagrum.InvalidArgument – If the size of a value is different from the domain side of the node
  • pyagrum.FatalError – If one value is a vector of 0s
  • pyagrum.UndefinedElement – If one node does not belong to the Bayesian network
